Shop replacement rubber tracks for New Holland equipment by machine model and track size. Match the width, pitch and link count to your existing track, and check each listing for compatible models and the quantity included.
Equipment Search & Filter
New Holland Rubber Tracks & Replacement Parts for Excavators and Skid Steers
New Holland equipment is used across excavation, construction, landscaping, utility work, and material-handling applications. Rio Rubber Track offers OEM-compatible replacement rubber tracks for New Holland equipment, including compact excavators and compact track loaders.
New Holland machines use different undercarriage configurations depending on the model. Rio's current listings include smaller mini excavator tracks such as 230x96x35 for the E18TR and E18IV, as well as larger configurations including 300x52.5x74, 300x52.5x82, 300x52.5x88, 400x72.5x74, 450x81x76, and 450x86x55 for specific New Holland applications.
NEW HOLLAND MINI EXCAVATOR RUBBER TRACKS
Rio's New Holland selection includes replacement tracks for compact excavators across different size classes. Because track dimensions vary considerably between models, the exact machine and existing track specification should be confirmed before ordering.
New Holland E18TR & E18IV
Rio lists a 230x96x35 rubber track for the New Holland E18TR and E18IV mini excavators.
The configuration measures 230 mm in width, 96 mm pitch, and 35 links. This is one of the narrower New Holland track configurations in Rio's current listings and is suited to compact excavator applications where maneuverability and access are important.
When replacing tracks on these machines, confirm the complete 230x96x35 specification rather than selecting a track based only on the machine's width.
New Holland EH25
For the New Holland EH25, Rio lists a 300x52.5x74 rubber track configuration.
The 300 mm width provides a different undercarriage configuration from the smaller E18-series application. The same size is also listed for several other equipment manufacturers, so the New Holland model should be verified along with the track measurements before purchase.
New Holland E30C
Rio also offers a 300x52.5x82 configuration for the New Holland E30C.
This track measures 300 mm wide, uses a 52.5 mm pitch, and contains 82 links. Although it has the same width and pitch as the EH25 configuration, the link count is different, demonstrating why all three track measurements should be checked before ordering.
NEW HOLLAND EH35B RUBBER TRACKS
The New Holland EH35B is listed with a 300x52.5x88 rubber track configuration.
Rio identifies the EH35B alongside other machines using the same 300 mm width, 52.5 mm pitch, and 88-link specification. This is another example of why New Holland replacement tracks should be matched to the complete track specification rather than selected from a general size category.
The EH35B and similar compact excavators can be used for excavation, trenching, landscaping, utility installation, and general construction work.
NEW HOLLAND EH45 RUBBER TRACKS
For the larger New Holland EH45, Rio lists a 400x72.5x74 rubber track.
The 400 mm-wide configuration is substantially larger than the 230 mm and 300 mm tracks used on the smaller New Holland excavator applications. Rio's listing also identifies this configuration across other equipment models, making exact machine verification important.
NEW HOLLAND E70 SR
Rio also lists a 450x81x76 rubber track for the New Holland E70 SR mini excavator.
This configuration measures 450 mm wide, with an 81 mm pitch and 76 links. It represents one of the larger New Holland excavator track configurations available in Rio's listings.
FIND THE CORRECT NEW HOLLAND RUBBER TRACK
New Holland equipment uses several different track specifications, including:
These are specific fitment examples and are not interchangeable simply because some dimensions are similar.
Before ordering, check the existing track for its molded size marking and confirm the width, pitch, and link count. If the marking is unclear, provide the exact New Holland model and existing track measurements to help identify the correct replacement.
Need help finding the correct New Holland rubber track?
Contact Rio Rubber Track with your machine model and track dimensions for fitment assistance and a quote.
Contact Rio SupportNEW HOLLAND COMPACT TRACK LOADER RUBBER TRACKS
New Holland compact track loaders use wider rubber tracks than many of the brand's mini excavators. Rio Rubber Track lists replacement options for several New Holland CTL models, including the C180, C185, C190, C232, C237, C238, LT185B, and LT190B.
New Holland C180, C185 & C190
Rio lists a 450x86x55 rubber track configuration for the New Holland C180, C185, and C190.
This configuration measures 450 mm wide, uses an 86 mm pitch, and has 55 links. These machines are part of New Holland's compact track loader range and are used for applications such as grading, material handling, site preparation, landscaping, and general construction work.
New Holland C232, C237 & C238
The same 450x86x55 configuration is also listed for the C232, C237, and C238. Rio's product listings group these New Holland models with other machines using the same track specification.
Because several New Holland CTL models use the same basic track dimensions, confirming the exact machine model remains important when selecting a replacement.
New Holland LT185B & LT190B
Rio also identifies the LT185B and LT190B with the 450x86x55 configuration. This gives customers another New Holland CTL application within the same track-size group.
NEW HOLLAND EQUIPMENT FOR DIFFERENT APPLICATIONS
New Holland tracked equipment can be used across a range of demanding work environments. Depending on the machine and configuration, applications can include:
Mini excavators are commonly selected where access and maneuverability are important, while compact track loaders provide a larger working platform for grading, loading, carrying, and other attachment-based applications.
POPULAR NEW HOLLAND RUBBER TRACK SIZES
Rio's current New Holland listings include several different track configurations:
| Track Size | Example New Holland Applications |
|---|---|
| 230x96x35 | E18TR, E18IV |
| 300x52.5x74 | EH25 |
| 300x52.5x82 | E30C |
| 300x52.5x88 | EH35B |
| 400x72.5x74 | EH45 |
| 450x81x76 | E70 SR |
| 450x86x55 | C180, C185, C190, C232, C237, C238 |
These configurations are associated with specific New Holland machine applications and should not be treated as interchangeable.
WHY TRACK WIDTH ALONE IS NOT ENOUGH
Two New Holland machines can have tracks with similar widths while using different pitches or link counts. For example, Rio lists several 300 mm-wide configurations, including 300x52.5x74, 300x52.5x82, and 300x52.5x88.
The width is the first measurement, but the complete specification determines the track configuration. Before ordering, confirm:
Track width
Pitch
Number of links
Machine model
Existing track markings
This is especially important when replacing tracks on older New Holland equipment or when the machine has previously received replacement undercarriage components.
NEW HOLLAND TRACK FITMENT CHECK
If the existing track has a molded size marking, use it to compare against the Rio product listing. If the marking is unavailable, measure the track and provide the exact New Holland model.
Photos of the existing track and undercarriage can also be useful when requesting fitment assistance. Providing complete information before ordering can help reduce the risk of selecting an incorrect configuration.
For compact track loaders such as the C180, C185, C190, C232, C237, and C238, verify that the existing track matches the 450x86x55 configuration listed by Rio before purchasing.
Need help matching a New Holland rubber track to your equipment? Send Rio Rubber Track your machine model and existing track dimensions for fitment assistance.
NEW HOLLAND RUBBER TRACKS FROM RIO RUBBER TRACK
New Holland equipment uses a wide range of rubber track configurations across its mini excavators and compact track loaders. Rio Rubber Track offers replacement options for specific New Holland models and track specifications, helping customers narrow down the correct replacement based on their machine and existing track.
Rio's listings include compact excavator configurations such as 300x52.5x74, 300x52.5x82, 300x52.5x88, and 400x72.5x74, along with wider CTL configurations such as 450x86x55.
NEW HOLLAND EXCAVATOR AND CTL FITMENT
Rio's New Holland listings cover different equipment categories and size ranges. For example, the E30C uses a 300x52.5x82 configuration, while the EH35B uses 300x52.5x88. The EH45 is listed with 400x72.5x74.
For compact track loaders, Rio lists the C180, C185, C190, C232, C238, LT185B, and LT190B with a 450x86x55 configuration.
This range makes it important to match the complete track specification to the exact machine rather than selecting a replacement based only on brand or track width.
NEW HOLLAND RUBBER TRACK FITMENT FAQs
Rio lists replacement rubber tracks for multiple New Holland excavators and compact track loaders. Applications include models such as the E30C, EH25, EH35B, EH45, E70 SR, C180, C185, C190, C232, C238, LT185B, and LT190B, depending on the track configuration.
Rio's New Holland listings include several configurations, such as 230x96x35, 300x52.5x74, 300x52.5x82, 300x52.5x88, 400x72.5x74, 450x81x76, and 450x86x55. The correct size depends on the specific New Holland machine and undercarriage.
The model number is an important starting point, but it is recommended to verify the existing track dimensions as well. Width, pitch, and link count should match the required configuration. This is especially important because Rio lists several New Holland machines with different track specifications.
A 450x86x55 rubber track is approximately 450 mm wide, has an 86 mm pitch, and contains 55 links. Rio lists this configuration for several New Holland compact track loaders, including the C180, C185, C190, C232, C238, LT185B, and LT190B.
Inspect the tracks for excessive tread wear, cracking, cuts, missing rubber, exposed steel cords, or other visible damage. Uneven wear should also be investigated before installing replacement tracks.
Yes. If you are unsure about the correct configuration, provide the New Holland model, track width, pitch, link count, and photos of the existing track when available. These details can help narrow down the appropriate Rio replacement.
REPLACE WORN NEW HOLLAND RUBBER TRACKS
The correct rubber track can help keep New Holland equipment ready for excavation, trenching, landscaping, grading, material handling, utility work, and construction applications.
Whether you operate a compact New Holland excavator or a larger compact track loader, start by identifying the exact machine and checking the existing track specification. Rio's New Holland listings provide multiple replacement configurations for different machine applications.
FIND THE RIGHT NEW HOLLAND RUBBER TRACK
Browse the New Holland rubber track collection to review available replacement options. If you cannot identify the correct track from the machine model or existing markings, contact Rio Rubber Track with your equipment details and track measurements.
Need replacement rubber tracks for your New Holland equipment? Contact Rio Rubber Track today with your machine model and existing track dimensions for fitment assistance and a quote.
Browse New Holland Rubber Tracks
