OEM-COMPATIBLE REPLACEMENT RUBBER TRACKS

Nissan Rubber Tracks & Replacement Parts for Mini Excavators

Nissan mini excavators are used for excavation, trenching, landscaping, utility work, site preparation, and other compact-equipment applications. Rio Rubber Track offers OEM-compatible replacement rubber tracks for Nissan excavators, with multiple track configurations covering different Nissan models and equipment sizes.

Nissan machines use different undercarriage specifications depending on the model. Rio's current listings include compact configurations such as 230x48x62, 230x96x33, and 250x72x45, as well as larger 300x52.5x74, 300x52.5x80, and 450x81x78 applications.

NISSAN H-SERIES RUBBER TRACKS

Rio lists a 230x48x62 rubber track for several smaller Nissan excavator applications, including the H12A, H15, H15A, H15B, and H15B Plus.

This configuration measures 230 mm in width, has a 48 mm pitch, and contains 62 links. The same specification is also listed across other compact excavator brands, so the exact Nissan model and existing track dimensions should be confirmed before ordering.

These smaller machines are suited to work where compact dimensions and maneuverability are important, including landscaping, utility work, residential excavation, and trenching.

230x48x62

Nissan H15 & Related Applications

The H15 family represents one of the smaller Nissan fitment groups in Rio's catalog. When replacing these tracks, checking the complete 230x48x62 specification is important rather than selecting a track based only on its 230 mm width.

NISSAN 120–230 SERIES RUBBER TRACKS

Rio also lists a 230x96x33 configuration for several Nissan excavator models, including the N120-2, N150-2, N150-2R, N230-2, and 150/N.

The track measures 230 mm wide, uses a 96 mm pitch, and has 33 links. This is a substantially different configuration from the 230x48x62 track used on the smaller H-series machines.

Because both configurations have the same 230 mm width, customers should verify the pitch and link count before ordering.

NISSAN N06, N060 & N120 RUBBER TRACKS

For another group of compact Nissan machines, Rio lists a 250x72x45 rubber track for the N06, N060, N120, and N120 R.

This configuration is 250 mm wide, with a 72 mm pitch and 45 links. It represents another distinct Nissan undercarriage configuration and should be matched to the exact machine application.

These compact excavator applications can be used for landscaping, trenching, construction, utility work, and other jobs where a smaller tracked machine is required.

NISSAN N220–N260 SERIES

Rio lists a 300x52.5x74 rubber track for several Nissan models in the N220–N260 range, including the N220-2, N230-2, N230-2R, N250-2, N260-2, and N260-2R.

This 300 mm-wide configuration is larger than the 230 mm and 250 mm applications above. The complete specification is 300 mm width × 52.5 mm pitch × 74 links.

The same configuration is also listed for Nissan Hanix H22, H24, and H27 models, providing additional fitment options within the Nissan/Hanix equipment family.

NISSAN N300 & N350 SERIES RUBBER TRACKS

For larger Nissan mini excavators, Rio lists a 300x52.5x80 rubber track for the N300-2, N300-2R, N35, N350-2, and N350-2R.

Although this configuration has the same 300 mm width and 52.5 mm pitch as the N220–N260 track discussed above, it uses 80 links instead of 74. This difference makes complete fitment verification essential.

FIND THE RIGHT NISSAN RUBBER TRACK

Rio's Nissan listings demonstrate the range of track specifications used across the brand:

  • 230x48x62 – H12A, H15, H15A, H15B
  • 230x96x33 – N120-2, N150-2, N150-2R, N230-2
  • 250x72x45 – N06, N060, N120, N120 R
  • 300x52.5x74 – N220-2, N230-2, N230-2R, N250-2, N260-2
  • 300x52.5x80 – N300-2, N300-2R, N35, N350-2, N350-2R

These are specific fitment examples and are not interchangeable simply because some dimensions are similar.

Before ordering, check the existing track for its molded size marking and confirm the width, pitch, and link count. If the marking is unclear, provide the exact Nissan model and existing track measurements to help identify the correct replacement.

Need help finding the correct Nissan rubber track? Contact Rio Rubber Track with your machine model and track dimensions for fitment assistance and a quote.

When requesting fitment assistance, provide:

  • ✓ Exact Machine Model
  • ✓ Track Width (mm)
  • ✓ Pitch Measurement (mm)
  • ✓ Total Link Count
  • ✓ Existing Track Markings / Photos
Get Fitment Assistance

NISSAN EXCAVATOR MODEL COVERAGE

Nissan's compact excavator range includes machines with several different undercarriage configurations. Rio Rubber Track's listings cover multiple Nissan and Nissan Hanix models, from smaller H-series machines to larger N-series excavators.

Nissan N300-2 & N350 Series

The N300-2, N300-2R, N35, N350-2, and N350-2R are listed with a 300x52.5x80 rubber track configuration. Rio also identifies Nissan Hanix H30 and H35 applications with the same specification.

The 300x52.5x80 configuration uses the same 300 mm width and 52.5 mm pitch as the 300x52.5x74 configuration used on several smaller N-series models, but it has 80 links instead of 74. This difference is important when confirming replacement fitment.

Nissan N220-2 Through N260-2

Rio lists the 300x52.5x74 configuration for the N220-2, N230-2, N230-2R, N250-2, N260-2, and N260-2R. The same listing includes Nissan Hanix H22, H24, and H27 applications.

These machines therefore share a different link count from the N300/N350 group even though both configurations use a 300 mm width and 52.5 mm pitch.

NISSAN HANIX RUBBER TRACK APPLICATIONS

Rio's catalog also identifies Nissan Hanix applications separately within several track-size listings. This includes the H22, H24, and H27 with the 300x52.5x74 configuration and the H30 and H35 with the 300x52.5x80 configuration.

When working with older Nissan Hanix equipment, checking the machine identification plate and existing track marking can be especially useful before ordering replacement tracks.

POPULAR NISSAN RUBBER TRACK SIZES

Rio's current Nissan fitment listings include several configurations:

Track Size Example Nissan Applications
230x48x62H12A, H15, H15A, H15B
230x96x33N120-2, N150-2, N150-2R, N230-2
250x72x45N06, N060, N120, N120 R
300x52.5x74N220-2, N230-2, N250-2, N260-2
300x52.5x80N300-2, N300-2R, N35, N350-2, N350-2R

These are machine-specific examples from Rio's product catalog. Similar-looking track sizes should not be assumed to be interchangeable without confirming the complete specification.

NISSAN RUBBER TRACKS FOR DIFFERENT APPLICATIONS

Nissan compact excavators can be used for jobs where smaller tracked equipment is needed for access and maneuverability. Depending on the machine, applications can include:

✓ Utility trenching
✓ Landscaping
✓ Residential excavation
✓ Drainage work
✓ Site preparation
✓ Foundation work
✓ General construction
✓ Underground utility installation

Rubber tracks can be useful when equipment needs to operate on surfaces where reducing ground disturbance is important. Actual machine capability depends on the excavator model, attachment, jobsite conditions, and operating practices.

WHY COMPLETE TRACK MEASUREMENTS MATTER

Nissan's Rio listings provide a good example of why track width alone is not enough to identify a replacement.

Several Nissan machines use a 300 mm-wide track, but Rio lists both 300x52.5x74 and 300x52.5x80 configurations. The difference in link count means these tracks should not automatically be considered interchangeable.

Before ordering, confirm:

  • Track width
  • Pitch
  • Number of links
  • Exact Nissan model
  • Existing track markings

If the track has a molded size marking, compare all three measurements with the Rio listing.

CHECK YOUR NISSAN TRACK BEFORE ORDERING

Inspect the existing rubber track for its size marking and overall condition. If the marking is difficult to read, measure the track and provide the Nissan model number.

Photos of the existing track can also help when requesting fitment assistance. For older Nissan and Nissan Hanix equipment, providing as much machine information as possible can help narrow down the correct configuration.

Not sure which Nissan rubber track fits your machine? Contact Rio Rubber Track with your model number and existing track dimensions for fitment assistance.

When requesting fitment assistance, provide:

  • ✓ Nissan model number
  • ✓ Track width (mm)
  • ✓ Pitch measurement (mm)
  • ✓ Total link count
  • ✓ Photos of existing track
Get Fitment Assistance

NISSAN RUBBER TRACKS FROM RIO RUBBER TRACK

Rio Rubber Track offers replacement rubber track options for a range of Nissan and Nissan Hanix mini excavators. Current Rio listings include Nissan applications such as the N300-2, N300-2R, N35, N350-2, and N350-2R using a 300 x 52.5 x 80 configuration, along with Nissan Hanix H30 and H35 models.

Because Nissan excavators can use different track configurations, choosing a replacement based only on the brand name is not recommended. The track width, pitch, and number of links should match the machine's existing undercarriage. Rio's product listings use these measurements to identify compatible track applications.

FITMENT SUPPORT FOR NISSAN EXCAVATORS

If the size marking on your Nissan rubber track is difficult to read, start with the machine model and the information available from the existing track. Photos of the track, model plate, and undercarriage can also help with identification.

This is especially useful when working with older Nissan equipment where the original track information may no longer be easy to locate. Providing the complete machine model and track dimensions gives Rio a better basis for confirming the appropriate replacement.

Rio also lists multiple Nissan and Nissan Hanix machines against the same track configuration. For example, the 300 x 52.5 x 80 track is listed for Nissan N300-2, N300-2R, N35, N350-2, and N350-2R, as well as Nissan Hanix H30 and H35.

NISSAN RUBBER TRACK FITMENT FAQs

What Nissan excavators can use Rio replacement rubber tracks?
Rio currently lists replacement rubber track applications for several Nissan and Nissan Hanix mini excavator models. Available applications vary by track size and configuration, so the specific machine model should be checked against the track dimensions before ordering.
Can I order Nissan rubber tracks using only the machine model?
The machine model is a useful starting point, but it is better to verify the track dimensions as well. Different models or configurations can use different track specifications. Check the width, pitch, and link count of your existing track whenever possible.
What does 300 x 52.5 x 80 mean?
The numbers identify the main track dimensions: 300 mm is the track width, 52.5 mm is the pitch between links, and 80 is the number of links. These measurements help match the replacement track to the excavator's undercarriage.
Can Nissan and Nissan Hanix models use the same rubber track?
Some Nissan and Nissan Hanix models are listed under the same track specification. For example, Rio's 300 x 52.5 x 80 listing includes Nissan N300-2 and N350-series applications along with Nissan Hanix H30 and H35. However, compatibility should always be confirmed for the specific machine.
What if I cannot find the size marking on my Nissan track?
Measure the track manually and record the width, pitch, and number of links. You can also provide the machine model, existing track photos, and any available part or serial information so the fitment can be checked before purchase.
Should I replace one Nissan rubber track or both?
For tracked equipment, replacing both tracks at the same time can help maintain more consistent wear and operation. If only one track needs replacement, compare the condition and wear of the other track before deciding. The replacement should match the required specification exactly.

KEEP YOUR NISSAN EXCAVATOR READY FOR WORK

A properly matched rubber track helps your Nissan mini excavator continue working across excavation, trenching, landscaping, utility, and construction applications. Rio Rubber Track provides multiple track configurations and Nissan-specific application information to make the replacement process easier.

Before ordering, have your Nissan model and current track dimensions available. If you are unsure about the correct size, contact Rio Rubber Track with the details of your machine and existing track for fitment assistance and a quote.

Why Choose Rio Rubber Tracks for Nissan Machines:

  • OEM-Compatible Undercarriage Fitment
  • High-Tensile Steel Internal Cords
  • Premium Cut & Tear-Resistant Compound
  • 100% Fitment Guarantee & Warranty Support
Request a Fitment Quote
